Pinokio

Minimal Chromium gateway written in Rust. It lets remote Puppeteer and Playwright clients connect to isolated Chromium instances over WebSocket, with token authentication, a concurrency limit, a FIFO queue and robust process cleanup.

Quick start

docker build -t pinokio .
docker run --rm -p 3000:3000 --shm-size=1g -e TOKEN=secret pinokio

Then connect:

const puppeteer = require("puppeteer-core");
const browser = await puppeteer.connect({
  browserWSEndpoint: "ws://localhost:3000?token=secret",
});

Architecture

src/
  main.rs        bootstrap, tracing, SIGTERM/SIGINT handling
  config.rs      env var parsing and validation (refuses to start on invalid values)
  errors.rs      error types mapped to HTTP status codes
  server.rs      Axum routes: / and /chromium (WebSocket), /health, /ready, /status
  auth.rs        token check (?token= or Authorization: Bearer), constant-time compare
  queue.rs       concurrency gate: session slots + FIFO queue
  chromium.rs    process launch, DevToolsActivePort discovery, SIGTERM/SIGKILL teardown
  session.rs     active session lifecycle and guaranteed cleanup
  proxy.rs       transparent bidirectional WebSocket relay (no CDP interpretation)

Session flow:

1. The client opens a WebSocket to / (or /chromium) with its token.
2. Before the upgrade is answered, the server authenticates the client, waits for a free slot (or queues the request), launches an isolated Chromium and connects to its local CDP endpoint. Any failure at this stage returns a proper HTTP status code.
3. The upgrade completes and the server relays frames between the client and Chromium without touching them.
4. When the client disconnects, Chromium exits, a timeout fires or the server shuts down, the session is torn down: Chromium process group killed (SIGTERM then SIGKILL), temp profile dir removed, slot released, next queued request served.

Concurrency invariants

• Slots are a tokio::sync::Semaphore with MAX_CONCURRENT_SESSIONS permits. Tokio semaphores wake waiters in FIFO order, which provides the fair queue and makes it impossible to bypass.
• Queue admission uses an atomic counter with a compare-and-swap loop: once MAX_QUEUE_LENGTH waiters are registered, the next request is rejected immediately with 429. With 10 slots and a queue of 20, the 31st concurrent request is refused.
• A permit is owned by its session and released exactly once when the session ends, including on panic (drop guard). A client that disconnects while queued is removed from the queue automatically because its request future is dropped.
• No status messages are sent on the main endpoint before proxying: standard CDP clients (Puppeteer, Playwright) would break. Queue visibility is provided by GET /status instead.

Chromium lifecycle

Each session launches its own process with --headless=new, --remote-debugging-port=0 and a unique temp --user-data-dir. The CDP port is read from the DevToolsActivePort file that Chromium writes in that directory; logs are never parsed. The CDP endpoint listens on 127.0.0.1 only and is never exposed.

Each Chromium runs in its own process group (setsid). Teardown signals only that group: SIGTERM, 3 s grace, then SIGKILL, then the child is reaped. In Docker, tini (PID 1) reaps any re-parented grandchildren. No global pkill is ever used.

Endpoints

Endpoint	Description
GET / or GET /chromium	WebSocket upgrade, creates a session and proxies CDP
GET /health	Liveness: {"status":"ok"}
GET /ready	Readiness: 200 when accepting requests, 503 when shutting down or saturated
GET /status	Counters: active/queued sessions vs limits (token-protected when auth is on)

HTTP errors before the upgrade:

Code	Meaning
401	Missing or invalid token
429	Queue full
503	Server shutting down or Chromium unavailable
504	Queue timeout or Chromium startup timeout

After the upgrade, sessions are closed with WebSocket codes 1000 (Chromium closed normally), 1001 (session timeout or server shutdown) or 1011 (Chromium error).

Configuration

All configuration is done through environment variables, validated at startup. Invalid values prevent the server from starting.

Variable	Default	Description
HOST	0.0.0.0	Bind address
PORT	3000	Listen port
TOKEN	empty	Shared secret; empty disables authentication
MAX_CONCURRENT_SESSIONS	10	Maximum simultaneously active Chromium sessions
MAX_QUEUE_LENGTH	20	Maximum requests waiting for a slot; beyond that, 429
CONNECTION_TIMEOUT_MS	600000	Maximum lifetime of an active session
QUEUE_TIMEOUT_MS	600000	Maximum wait in the queue
CHROME_STARTUP_TIMEOUT_MS	15000	Time Chromium gets to publish its CDP endpoint
SHUTDOWN_GRACE_PERIOD_MS	10000	Time given to active sessions after SIGTERM/SIGINT
CHROME_PATH	/usr/bin/chromium	Chromium or Google Chrome binary
CHROME_HEADLESS	true	Run with --headless=new
CHROME_NO_SANDBOX	true	Add --no-sandbox (see security notes)
CHROME_DISABLE_DEV_SHM_USAGE	true	Add --disable-dev-shm-usage
CHROME_EXTRA_ARGS	empty	Extra Chromium args, whitespace-separated
LOG_LEVEL	info	trace, debug, info, warn, error
TZ	system	Timezone inherited by Chromium
LANGUAGE	system	Locale, also passed as Chromium --lang

Clients cannot modify Chromium launch arguments. Query parameters other than token are ignored. Server-wide flags such as --disable-web-security or --window-size go in CHROME_EXTRA_ARGS.

Client compatibility

Puppeteer (works as-is)

const puppeteer = require("puppeteer-core");

const browser = await puppeteer.connect({
  browserWSEndpoint: "ws://localhost:3000?token=secret",
});
try {
  const page = await browser.newPage();
  await page.goto("https://example.com");
  console.log(await page.title());
} finally {
  await browser.close();
}

Playwright (CDP over a ws URL)

const { chromium } = require("playwright");

const browser = await chromium.connectOverCDP("ws://localhost:3000?token=secret");
try {
  const context = await browser.newContext();
  const page = await context.newPage();
  await page.goto("https://example.com");
  console.log(await page.title());
} finally {
  await browser.close();
}

Compatibility notes:

• Pinokio exposes a raw CDP WebSocket endpoint, not a Playwright-native (connect()) endpoint. Playwright must use connectOverCDP, which is Chromium-only and skips some Playwright-managed niceties (it attaches to the existing browser instead of controlling launch).
• The http:// form of connectOverCDP is not supported: it relies on a GET /json/version discovery request, which would require creating the session outside the WebSocket handshake. Use the ws:// form, verified to work.
• wss:// is handled by your reverse proxy (Traefik, Nginx, Caddy, HAProxy); Pinokio itself does not terminate TLS.

Docker

The provided Dockerfile builds a multi-stage image: Rust builder, then a Debian slim runtime with Chromium, running as a non-root user with tini as PID 1 and a healthcheck on /health.

Example compose service:

services:
  pinokio:
    build: ./pinokio
    restart: unless-stopped
    ports:
      - "3000:3000"
    shm_size: "1gb"
    environment:
      TOKEN: "${PINOKIO_TOKEN:-}"
      MAX_CONCURRENT_SESSIONS: 10
      MAX_QUEUE_LENGTH: 20
      CONNECTION_TIMEOUT_MS: 600000
      TZ: "Europe/Paris"
      LANGUAGE: "fr-FR"

shm_size matters: Chromium uses /dev/shm for rendering buffers and the Docker default of 64 MB makes tabs crash under load. Give it 1 GB, or keep CHROME_DISABLE_DEV_SHM_USAGE=true (then Chromium falls back to /tmp, slightly slower but safe).

Security notes

• The Chromium CDP port listens on 127.0.0.1 inside the container and is never exposed; only the authenticated proxy reaches it.
• Each session gets a unique temp profile directory, removed at teardown.
• Clients cannot inject launch arguments or execute anything server-side; the server never interprets CDP payloads.
• WebSocket frames are capped at 16 MiB (64 MiB per message) in both directions.
• --no-sandbox disables Chromium's internal sandbox. It is required in most containers (no user namespaces). Mitigations: the container runs as a non-root user, one Chromium per session, and pages you drive are the main threat, so avoid pointing sessions at untrusted content with sensitive credentials loaded. If your kernel allows it, set CHROME_NO_SANDBOX=false.
• Tokens are never logged; neither are CDP payloads or page contents.

Known limitations

• One WebSocket connection = one Chromium instance. There is no session reuse, prebooting or browserWSEndpoint reconnection to a running session.
• Playwright only via connectOverCDP with a ws:// URL (no /json/version discovery, no Playwright-native protocol).
• Metrics are limited to the /status counters.

License

Proprietary. Use is permitted only as part of the Puppetflow product; see LICENSE. Third-party dependencies (Rust crates, Chromium) keep their own licenses.
