Atlas

Distributed headless mineflayer bot system for anarchy servers.

Architecture: Modular ES Modules
Runtime: Node.js 18+
Language: TypeScript 5.3
State: Singleton pattern with getter/setter access

---

Quick Reference

Command	Description
npm run bot	Start bot instance
npm run cli	Interactive CLI tool
npx tsc --noEmit	Type-check

---

Directory Structure

packages/
├── core/           # Orchestration layer
│   ├── bot.ts         # Entry point
│   ├── config.ts      # Centralized configuration
│   ├── connection.ts  # Server connection logic
│   ├── events.ts      # Event handlers
│   ├── lifecycle.ts   # Bot lifecycle management
│   └── state.ts       # Singleton state management
├── functions/      # Complex behaviors
│   └── orbit.ts       # Orbital flight mechanics
├── storage/        # Persistence layer
│   └── database.ts    # SQLite interface
├── tools/          # CLI tooling
│   └── cli.ts
└── utils/          # Implementation layer
    ├── chat.ts
    ├── inventoryManagement.ts
    ├── elytraMovement.ts
    ├── storageBlocks.ts
    ├── blockInteractions.ts
    ├── brand.ts
    ├── plugins.ts
    └── commands/        # Whisper command handlers

---

Configuration API

Config.category.setting pattern. All hardcoded values centralized.

Config.server.host          // '8b8t.me'
Config.server.version       // '1.20.1'
Config.auth.type            // 'offline'
Config.target.player        // 'Raphiel'
Config.orbit.radius         // 7
Config.elytra.maxSpeed      // 40 (blocks/s)
Config.elytra.gravityCompensation  // 0.02 (calibrated)
Config.security.allowedUsers // ['user1', 'user2']

---

State Management

Centralized via packages/core/state.ts.

// Getters
State.isLoggedIn()          // boolean
State.isReady()             // boolean
State.getCurrentWorld()     // 'none' | 'lobby' | 'survival'
State.isElytraDeployed()    // boolean
State.getCurrentStorage()   // Container | null

// Setters
State.setLoggedIn(true)
State.setReady(true)
State.enterLobby()
State.enterSurvival()
State.setElytraDeployed(true)

---

Elytra Movement API

// Deployment
ElytraMovement.hoverElytra(bot)           // 0-gravity hover
ElytraMovement.deployElytra(bot)          // Standard flight

// Movement
ElytraMovement.moveElytra(bot, direction, blocks)
// direction: 'up' | 'down' | 'left' | 'right' | 'forward' | 'backward'

// State validation
ElytraMovement.isActuallyDeployed(bot)    // Heuristic detection
ElytraMovement.validateElytraState(bot)   // Auto-correct if mismatched

// Control
ElytraMovement.stopElytra(bot)
ElytraMovement.forceStopElytra(bot)
ElytraMovement.setElytraControl(bot, state, value)

Implementation Details:

• Custom physics tick overrides plugin default (forces +0.07545 Y/tick)
• Gravity compensation: 0.02 blocks/tick (calibrated for 8b8t)
• Altitude lock during horizontal movement
• 500ms post-movement correction phase
• Speed: proportional to distance, clamped 5-40 blocks/s

---

Command System

Whisper-based command interface.

// Registration (packages/utils/commands/index.ts)
import * as elytra from './elytra.js';
registerCommand(elytra.name, elytra.execute);

// Handler signature
export function execute(
  bot: mineflayer.Bot,
  username: string,
  args: string[]
): void | Promise<void>

Available Commands:

Command	Args	Description
!elytra	-	Deploy elytra (0-gravity hover)
!elytra up	[blocks=1]	Move up N blocks
!elytra down	[blocks=1]	Move down N blocks
!elytra forward	[blocks=1]	Move forward N blocks
!elytra backward	[blocks=1]	Move backward N blocks
!elytra left	[blocks=1]	Move left N blocks
!elytra right	[blocks=1]	Move right N blocks
!drop	<item> [count]	Drop items from inventory
!say	<message>	Send chat message
!placeBlock	-	Place held block
!takeItem	<item>	Take item from storage
!testInventory	-	Debug inventory state

---

Inventory Management

// Slot ranges
SLOTS.ARMOR_TORSO      // 6 (elytra slot)
SLOTS.HOTBAR_START     // 36
SLOTS.HOTBAR_END       // 44
SLOTS.OFFHAND          // 45

// Operations
Inventory.findItem(bot, 'elytra')
Inventory.equipElytra(bot)           // Promise<boolean>
Inventory.getHeldItem(bot)
Inventory.getArmor(bot)
Inventory.dropItem(bot, itemName, count)

---

Brand Spoofing

Intercepts minecraft:brand custom_payload packet.

// Spoofs to 'vanilla' to avoid detection
const clientWrite = bot._client.write.bind(bot._client);
bot._client.write = function(name: string, params: unknown): void {
  if (name === 'custom_payload' && isBrandPayload(params)) {
    const vanillaBuf = Buffer.concat([
      Buffer.from([7]),
      Buffer.from('vanilla')
    ]);
    clientWrite(name, { channel: 'minecraft:brand', data: vanillaBuf });
    return;
  }
  clientWrite(name, params);
};

---

World Detection

Dual-spawn detection for networked servers with login plugins.

Spawn 1 (none → lobby)     : Initial connection, send /login
Spawn 2 (lobby → survival) : Post-teleport, bot is "logged in"

bot.on('spawn', () => {
  if (State.getCurrentWorld() === 'none') {
    State.enterLobby();
    Chat.sendLogin(bot, password);
  } else if (State.getCurrentWorld() === 'lobby') {
    State.enterSurvival();
    // Begin bot behavior
  }
});

---

Dependency Flow

bot.ts (top level)
  ↓
core modules (orchestration)
  ↓
functions / utils (implementation)
  ↓
storage (persistence)

Lower levels NEVER import from higher levels.

---

Console Prefixes

Prefix	Usage
[FATAL]	Unrecoverable error, exit code 1
[ERROR]	Recoverable error
[WARN]	Warning, non-critical
[INFO]	General information
[CMD]	Command execution
[CHAT]	Chat message logging

---

Key Discoveries

Elytra Physics:

• Plugin default: +0.07545 Y/tick (causes rapid ascent)
• Fix: Override onTick, set Y velocity directly to 0.02
• Horizontal drift fix: Lock altitude + 500ms correction phase

State Validation:

const actualDeployed = pluginFlying || (elytraEquipped && !onGround);

Momentum Cancellation:

// Wrong - accumulates momentum
vel.y += GRAVITY_COMPENSATION;

// Correct - cancels momentum
bot.entity.velocity.set(vel.x, GRAVITY_COMPENSATION, vel.z);

Full discoveries: docs/discoveries.md

---

TypeScript Constraints

• Use any for mineflayer/prismarine types (no exports)
• Always .js extension in imports (ES modules)
• No @ts-ignore without understanding why
• Run npx tsc --noEmit before commit

---

Conventional Commits

feat:     New feature
fix:      Bug fix
refactor: Code change, same behavior
docs:     Documentation only
chore:    Build/tooling changes

One logical change per commit. Keep messages under 72 characters.
