🛡️ AI-Enhanced Surveillance System

A production-ready, zero-cost AI surveillance platform with real-time face recognition, live RTSP stream processing, and multi-channel alert dispatch.

---

📖 Table of Contents

• Features
• Tech Stack
• Architecture
• Prerequisites
• Quick Start
• API Reference
• Alert Channels Setup
• Troubleshooting

---

✨ Features

🧑‍🤝‍🧑 Person Enrollment

• Intelligent Enrollment: Enroll suspects, victims, or accused persons with a face photo.
• High Accuracy: Add multiple images per person — embeddings are averaged for superior accuracy.
• Instant Search: Quick image search to identify a person from any uploaded photo.

📹 Live Camera Streams

• Universal Support: Register RTSP cameras, IP cameras, or webcams (source 0).
• Granular Control: Start/stop streams from the UI — each stream runs as an isolated Celery task.
• Custom Configuration: Per-camera settings for match threshold, frame skip, and GPS coordinates.
• Targeted Alerts: Per-camera police station alert routing via Webhook, Telegram, and ntfy.

🖼️ Media Analysis

• Offline Processing: Upload images or videos for offline face matching.
• Background Jobs: Video jobs run in the background with granular per-frame progress tracking.

🚨 Detection & Alerting

Confidence Score	Threat Level	Automated Action
≥ 0.60	🔴 HIGH	Auto-alert dispatched to all configured channels
0.45–0.59	🟡 REVIEW	Saved to Review Queue for operator confirmation
< 0.45	⚪ LOW	Not recorded

• Multi-Channel: Per-person & Per-camera routing to Telegram, Email, ntfy.sh, and Webhooks.
• Smart Throttling: 60-second cooldown per person per camera to prevent alert spam.

---

🛠 Tech Stack

Layer	Technology
Face Recognition	InsightFace buffalo_l — ArcFace R100 (99.77% LFW)
Face Detection	RetinaFace (bundled in InsightFace)
Multi-object Tracking	DeepSORT (deep-sort-realtime)
Backend API	FastAPI + python-socketio (single ASGI process)
Task Queue	Celery + Redis
Database	MongoDB 7 — Motor (async) + pymongo (sync)
Frontend	React 18 + TypeScript + Vite + Tailwind CSS
Real-time Events	Socket.IO over Redis Pub/Sub
Alert Channels	Telegram Bot API, Gmail SMTP, ntfy.sh, HTTP Webhooks

---

🏗 Architecture

graph TD
    Browser[Browser / React App]
    FastAPI[FastAPI Backend]
    Celery[Celery Workers]
    Redis[Redis Pub/Sub & Broker]
    Mongo[(MongoDB)]
    InsightFace[InsightFace + DeepSORT]

    Browser -- REST /api/* --> FastAPI
    Browser <--> |WebSocket /socket.io| FastAPI
    FastAPI <--> Redis
    Celery <--> Redis
    Celery --> InsightFace
    FastAPI --> Mongo
    Celery --> Mongo

Loading

Key Design Decisions:

• socketio.ASGIApp wraps FastAPI — single process, single port 8000.
• Workers publish detection events to Redis channel "detections"; a FastAPI background coroutine subscribes and re-emits via Socket.IO to all browser clients.
• All enrolled embeddings are loaded into a (N, 512) numpy matrix at startup — matching is one matmul call, O(1) regardless of enrolled persons count.
• DeepSORT tracks identities across frames and averages embeddings over a 5-frame buffer — reduces false positives from motion blur and partial occlusion.

---

🚀 Quick Start

Prerequisites

• Docker Desktop (provides Redis & optionally MongoDB)
• Python 3.10+
• Node.js 18+

⚠️ Windows users: If you have a native MongoDB service installed, please read the MongoDB setup section before proceeding.

1. Clone & Configure

cd AI-Enhanced-Surveillance
cp backend/.env.example backend/.env

Edit backend/.env with your desired configuration (Alert channels are optional).

2. Start Infrastructure

docker compose up -d

3. Start Backend

cd backend
python -m venv .venv

# Windows:
.venv\Scripts\activate
# macOS/Linux:
source .venv/bin/activate

pip install -r requirements.txt
uvicorn app.main:app --reload --host 0.0.0.0 --port 8000

💡 Note: The first run downloads the InsightFace buffalo_l model (~180 MB). 🪟 Windows users need Visual C++ Build Tools installed for InsightFace.

4. Start Celery Worker (In a new terminal)

cd backend
.venv\Scripts\activate   # or source .venv/bin/activate

# Windows (must use threads pool):
celery -A app.tasks.celery_app worker --loglevel=info --pool=threads --concurrency=4

# macOS/Linux:
celery -A app.tasks.celery_app worker --loglevel=info

5. Start Frontend (In a new terminal)

cd frontend
npm install
npm run dev

Open http://localhost:5173 in your browser! 🎉

---

📡 API Reference

Access interactive Swagger docs at: http://localhost:8000/docs

Click to expand basic API routes

Method	Path	Description
GET	/health	System health + enrolled person count
GET	/api/persons	List enrolled persons
POST	/api/persons	Enroll person
POST	/api/cameras	Register camera
POST	/api/cameras/{id}/start	Start stream worker
POST	/api/media/upload	Upload media for analysis
GET	/api/detections	Detections history

---

🔔 Alert Channels Setup

Telegram

1. Message @BotFather → /newbot → copy the token.
2. Start a DM with the bot, then fetch the chat ID: https://api.telegram.org/bot<TOKEN>/getUpdates.
3. Set TELEGRAM_BOT_TOKEN in .env.

Gmail

1. Enable 2-Step Verification on your Google account.
2. Go to Security → App Passwords and create one for "Mail".
3. Use the 16-character app password as SMTP_PASS.

ntfy.sh

1. No account needed — pick any unique topic name.
2. Subscribe at https://ntfy.sh/<your-topic> or via the mobile app.
3. Enter the topic name per-person or per-camera in the UI.

---

⚙️ Environment Variables

Variable	Default	Description
MONGO_URI	mongodb://localhost:27017/	MongoDB connection string
MONGO_DB_NAME	AI_Enhanced_Service	Database name (case-sensitive)
REDIS_URL	redis://localhost:6379/0	Redis connection string
UPLOADS_DIR	uploads	Directory for face crop snapshots
TELEGRAM_BOT_TOKEN	—	From @BotFather
SMTP_HOST	smtp.gmail.com	SMTP server
NTFY_BASE_URL	https://ntfy.sh	ntfy server URL

---

🛠️ Troubleshooting

DatabaseDifferCase error on startup

A database with a different case (AI_Enhanced_service) already exists. Drop it:

python -c "from pymongo import MongoClient; MongoClient().drop_database('AI_Enhanced_service')"

Celery not processing tasks on Windows

Must use `--pool=threads`. The default prefork pool requires fork() which is unavailable on Windows.

InsightFace install fails

Install Visual C++ Build Tools first: Visual Studio

Port 27017 conflict / Native MongoDB on Windows

Windows often ships with a native MongoDB service that conflicts with the Docker container. Check with: Get-Service -Name "*mongo*"

Either stop it in Admin PowerShell: Stop-Service MongoDB

Or stop the Docker Mongo and use the native one: docker compose stop mongo

---

💖 Support

Consider supporting by:



---

📜 License

Distributed under the Apache-2.0 License. See LICENSE for more information.

---
