Malachi

An open-source, 100% Elixir reimplementation of LinkedIn's NorthGuard log-storage architecture, a CP (consistent, partition-tolerant), horizontally-scalable log broker. Clients speak topics, keys, and opaque cursors: never partitions or offsets - so the broker can split, merge, and restripe its storage underneath without breaking clients. Replicated by quorum (Raft via ra), with SWIM membership, self-healing, and rack-aware placement.

Warning

Active development, not production-ready. Malachi is a work in progress: interfaces and on-disk formats can change, it has not been battle-tested at scale, and there is no stability or durability guarantee yet. Use it to learn and experiment, not to run production workloads.

💖 Sponsors

Become a sponsor and get your logo on our README on GitHub with a link to your site. [Become a sponsor]

Backers

Support us with a monthly donation and help us continue our activities. [Become a backer]

Introduction

🧭 The model (a log, not a queue)

A client deals in three things and nothing else:

topic: a named, ordered, replicated log.
key: on produce, routes each record to a range of the topic's keyspace (ordering is per key).
opaque cursor: on consume, a position token the client echoes back. It is deliberately opaque: internally it encodes per-range positions, but the client never sees partitions or offsets, so the broker can split/merge/restripe ranges underneath without breaking the client. This is the core difference from Kafka, which leaks partitions and offsets to the client.

Under the hood a topic is a set of dynamic ranges (slices of the keyspace that split as they grow), each a series of segments replicated by quorum across nodes. See docs/ARCHITECTURE.md for the full architecture.

⚡ Getting started (local)

Requires Elixir ~> 1.19 / OTP 28+.

git clone https://github.com/HectorIFC/malachi.git
cd malachi
mix deps.get
iex -S mix        # starts the broker: TCP on 4040, dashboard on 4041

The quickest way to see the model is the in-process log API in that iex session:

alias Malachi.LogApi
broker = Malachi.LogBroker

LogApi.create_topic(broker, "events")

# produce by key: no partitions, no offsets exposed
LogApi.produce(broker, "events", [
  %{"key" => "user-1", "value" => "hello"},
  %{"key" => "user-2", "value" => "world"}
])

# consume from the start: get back records + an opaque cursor to resume from
{:ok, records, cursor} = LogApi.fetch(broker, "events", :start, 100)
Enum.map(records, & &1.value)        #=> ["hello", "world"]

# resume by passing the cursor back, nothing new yet
{:ok, [], _cursor} = LogApi.fetch(broker, "events", cursor, 100)

A single node writes its segments to disk under a temp directory by default, so point MALACHI_LOG_DATA_DIR and MALACHI_RA_DATA_DIR at a real volume to keep data across restarts; set MALACHI_LOG_CLUSTER / MALACHI_LOG_NODES for a replicated, HA control plane over ra. Over the network, external clients speak the binary protocol on port 4040.

Node discovery (libcluster)

For a multi-node deploy, set MALACHI_CLUSTER_STRATEGY to have libcluster discover and connect peers over Erlang distribution automatically (run each node distributed, e.g. --sname/--name). This is connectivity-only: SWIM and the ra control plane still take their initial member set from MALACHI_LOG_NODES, and membership changes ride on the rebalancing coordinator. Absent the variable, nothing changes (single-node, no distribution required).

gossip: UDP multicast, near-zero config (dev/LAN). Tune with MALACHI_CLUSTER_GOSSIP_PORT, MALACHI_CLUSTER_GOSSIP_SECRET, MALACHI_CLUSTER_GOSSIP_MULTICAST_ADDR.
kubernetes: pod discovery via the Kubernetes API. Requires MALACHI_CLUSTER_KUBERNETES_SELECTOR and MALACHI_CLUSTER_KUBERNETES_NODE_BASENAME; optional MALACHI_CLUSTER_KUBERNETES_NAMESPACE and MALACHI_CLUSTER_KUBERNETES_MODE (hostname/ip/dns).
epmd: a static host list, reusing MALACHI_LOG_NODES, that libcluster keeps connected.

For a full multi-node deploy, deploy/kubernetes/ ships a worked example: a 3-node CP cluster as a StatefulSet with stable Raft identities, zone-aware placement (min_domains), and the health/readiness probes wired up.

🚀 Quick Start with Docker

Multi-Architecture Support: Works on AMD64 (Intel/AMD) and ARM64 (Apple Silicon, AWS Graviton)

Pull and Run

docker pull hectorcardoso/malachi:latest

docker run \
  --name malachi \
  -p 4040:4040 \
  -p 4041:4041 \
  -e MALACHI_ADMIN_PASS=your_secure_password \
  hectorcardoso/malachi:latest

Using Docker Compose

git clone https://github.com/HectorIFC/malachi.git
cd malachi
docker-compose up -d

Access the dashboard at: http://localhost:4041

Build Locally (All Platforms)

# Build for your current architecture
make docker-build

# Build for multiple architectures (requires Docker Buildx)
make docker-buildx-setup
make docker-buildx

# Build and push to Docker Hub (multi-arch)
make docker-buildx-push

See Multi-Architecture Build Guide for detailed instructions.

🛡️ Security Features

Malachi ships with security hardening on by default:

TLS 1.2/1.3 Enforcement - Required by default in production with certificate validation at startup
Argon2 Password Hashing - Industry-standard password hashing replacing SHA-256
Rate Limiting - Token bucket limiting on authentication (TCP and dashboard login), keyed by IP
Connection Controls - Per-IP and global connection limits to prevent DoS
Input Validation - Topic name allowlist (path-traversal safe), a configurable frame-size cap, and malformed-frame handling at the connection boundary
Streaming Backpressure - credit-window flow control on push subscriptions (a slow consumer applies backpressure instead of overflowing)
Dashboard Security - CSP, HSTS, CORS, X-Frame-Options, authentication required by default
Audit Logging - JSON-formatted security event logging with automatic rotation
Account Lockout - Progressive lockout after failed authentication attempts
Atom Exhaustion Prevention - BEAM atom table monitoring with configurable thresholds
Memory Monitoring - Automatic GC triggers and memory usage alerts
Security CI/CD - Automated scanning with Gitleaks, Trivy, Sobelow, and CodeQL

For complete configuration, see SECURITY.md and the Security Hardening section below.

📦 Ports

Port	Description
4040	TCP log protocol (binary)
4041	Web Dashboard

📈 Observability

Unauthenticated HTTP endpoints on the dashboard port (for load balancers and k8s probes):

Endpoint	Purpose	Returns
`GET /health`	Liveness	`200 {"status":"ok"}` while the node is up
`GET /ready`	Readiness	`200 {"status":"ready"}` once the log broker is running, else `503 {"status":"not_ready"}`

Example k8s probes:

livenessProbe:  { httpGet: { path: /health, port: 4041 } }
readinessProbe: { httpGet: { path: /ready,  port: 4041 } }

Prometheus metrics

GET /metrics serves the Prometheus text exposition (v0.0.4) when the scraper asks for it (Accept: text/plain), and the JSON dashboard payload otherwise, same path, content-negotiated. Series are namespaced malachi_: BEAM health (malachi_process_count, malachi_memory_bytes, malachi_uptime_seconds, …), security counters (malachi_rate_limit_blocked_total, malachi_failed_auth_total, malachi_tls_handshakes_total, …), operation totals fed by the telemetry events (malachi_records_produced_total, malachi_bytes_produced_total, malachi_records_consumed_total, malachi_auth_attempts_total{result}, malachi_replication_commits_total{result}), and per-topic gauges (malachi_topic_ranges, malachi_topic_segments, malachi_topic_bytes, malachi_domain_violations: segments spanning fewer than min_domains failure domains, …).

/metrics requires authentication (any user), so a scrape config passes a token:

scrape_configs:
  - job_name: malachi
    scheme: http
    authorization: { credentials: "<token from POST /login>" }
    static_configs: [{ targets: ["malachi-host:4041"] }]

Telemetry events

Malachi emits :telemetry events on its hot paths: attach a handler to feed metrics, logs, or traces (see Malachi.Telemetry):

Event	Measurements	Metadata
`[:malachi, :produce]`	`%{count, bytes}`	`%{topic}`
`[:malachi, :consume]`	`%{count}`	`%{topic}`
`[:malachi, :auth]`	`%{count: 1}`	`%{result: :ok \| :error}`
`[:malachi, :replication, :commit]`	`%{count}`	`%{result: :ok \| :no_quorum}`

:telemetry.attach("my-handler", [:malachi, :produce], fn _e, m, meta, _ ->
  IO.inspect({meta.topic, m.count, m.bytes})
end, nil)

Tracing (OpenTelemetry)

Client operations are traced with OpenTelemetry: malachi.produce and malachi.consume spans carry malachi.topic, malachi.records, and malachi.bytes attributes. A produce is a distributed trace: its context propagates across processes and nodes into child spans malachi.broker.produce and malachi.replication.commit (the quorum commit on the primary). Tracing is off by default, the sampler drops every span, so there is no per-operation cost until you opt in. To trace, turn the sampler on, add {:opentelemetry_exporter, "~> 1.8"}, and point it at your collector:

config :opentelemetry, sampler: :always_on, span_processor: :batch, traces_exporter: :otlp

config :opentelemetry_exporter,
  otlp_protocol: :http_protobuf,
  otlp_endpoint: "http://collector:4318"

🔐 Authentication

Malachi requires authentication for all producers and consumers. Users and permissions are replicated across the cluster via a dedicated Raft (ra) group, so a user created on one node exists on every node and survives restarts.

Default Users (development)

In dev/test these convenience users are seeded:

Username	Password	Permissions
admin	admin123	Full access
producer	producer123	Produce only
consumer	consumer123	Consume only
app	app123	Produce & Consume

⚠️ These weak defaults exist only in dev/test and are never shipped to production.

First boot in production

No default credentials ship. On first boot, if you have not set MALACHI_ADMIN_PASS, Malachi generates a random admin password and logs it once: save it from the logs (it cannot be recovered). Provide your own with MALACHI_ADMIN_PASS (and MALACHI_PRODUCER_PASS / MALACHI_CONSUMER_PASS / MALACHI_APP_PASS for the other service accounts), or set MALACHI_DISABLE_DEFAULT_USERS=true to seed nothing and manage users yourself.

Environment Variables

Variable	Default	Description
`MALACHI_TCP_PORT`	4040	TCP server port
`MALACHI_DASHBOARD_PORT`	4041	Dashboard port
`MALACHI_LOCALE`	en_US	Language (en_US, pt_BR)
`MALACHI_ADMIN_PASS`	admin123	Admin password
`MALACHI_PRODUCER_PASS`	producer123	Producer password
`MALACHI_CONSUMER_PASS`	consumer123	Consumer password
`MALACHI_APP_PASS`	app123	App password
`MALACHI_SESSION_TIMEOUT_SEC`	3600	Session timeout (1h)
`MALACHI_ENABLE_TLS`	false	Enable TLS encryption
`MALACHI_TLS_CERTFILE`	-	TLS certificate file path
`MALACHI_TLS_KEYFILE`	-	TLS private key file path
`MALACHI_TLS_CACERTFILE`	-	TLS CA certificate (optional)
`MALACHI_REQUIRE_TLS`	true (prod)	Require TLS in production
`MALACHI_TLS_VERSIONS`	tlsv1.3,tlsv1.2	Allowed TLS versions
`MALACHI_RATE_LIMIT_ENABLED`	true	Enable rate limiting
`MALACHI_AUTH_RATE_LIMIT`	10	Auth attempts per window
`MALACHI_AUTH_RATE_WINDOW_MS`	60000	Auth rate limit window (ms)
`MALACHI_PUBLISH_RATE_LIMIT`	1000	Publish messages per window
`MALACHI_PUBLISH_RATE_WINDOW_MS`	1000	Publish rate limit window (ms)
`MALACHI_SUBSCRIBE_RATE_LIMIT`	100	Subscribe requests per window
`MALACHI_SUBSCRIBE_RATE_WINDOW_MS`	60000	Subscribe rate limit window (ms)
`MALACHI_MAX_CONN_PER_IP`	100	Max connections per IP
`MALACHI_MAX_TOTAL_CONN`	10000	Max total connections
`MALACHI_CONNECTION_LIMIT_ENABLED`	true	Enable connection limiting
`MALACHI_MAX_AUTH_ATTEMPTS`	5	Failed auth attempts before lockout
`MALACHI_LOCKOUT_DURATION_MS`	300000	Initial lockout duration (5 min)
`MALACHI_PROGRESSIVE_LOCKOUT`	true	Enable progressive lockout
`MALACHI_SESSION_IP_BINDING`	true	Bind sessions to source IP
`MALACHI_MIN_PASSWORD_LEN`	12	Minimum password length
`MALACHI_ATOM_WARNING_THRESHOLD`	0.7	Atom table warning at 70%
`MALACHI_ATOM_CRITICAL_THRESHOLD`	0.9	Atom table critical at 90%
`MALACHI_GC_THRESHOLD_MB`	500	Auto-GC memory threshold (MB)
`MALACHI_LOG_CLUSTER`	(unset)	Enable the replicated control plane (peer cluster name)
`MALACHI_LOG_NODES`	(unset)	Peer node names for the replicated log
`MALACHI_LOG_REPLICATION_FACTOR`	3	Segment replicas (clamped to node count)
`MALACHI_LOG_SPREAD_BY`	(unset)	Broker attribute to spread replicas over (e.g. `rack`), rack/DC-aware placement
`MALACHI_LOG_MIN_DOMAINS`	(unset)	Min distinct `spread_by` domains a segment's replicas must span
`MALACHI_LOG_PLACEMENT_POLICY`	soft	`hard` fails a produce that cannot meet `min_domains`; `soft` places best-effort
`MALACHI_AUTO_REBALANCE`	false	Auto-commit vnode rebalancing on membership change (else operator-driven)
`MALACHI_AUTO_REBALANCE_INTERVAL_MS`	30000	Reconcile interval for auto-rebalancing
`MALACHI_AUTO_REBALANCE_STABILIZATION`	3	Consecutive stable reconciles before an auto-commit (absorbs flaps)
`MALACHI_SHUTDOWN_GRACE_MS`	5000	Drain window on shutdown after the acceptor quiesces, before closing connections
`MALACHI_CLUSTER_STRATEGY`	(unset)	Node discovery: `gossip`, `kubernetes`, or `epmd` (see below)
`MALACHI_CLUSTER_KUBERNETES_SELECTOR`	(unset)	k8s pod selector, e.g. `app=malachi` (kubernetes strategy)
`MALACHI_CLUSTER_KUBERNETES_NODE_BASENAME`	(unset)	k8s node basename, e.g. `malachi` (kubernetes strategy)
`MALACHI_MAX_FRAME_SIZE`	16777216	Max request frame bytes (also `:max_frame_size` app env)
`MALACHI_AUDIT_LOG_OUTPUT`	both	Audit log output (file/stdout/both/ets_only)
`MALACHI_AUDIT_LOG_FILE`	/var/log/malachi/audit.log	Audit log file path
`MALACHI_AUDIT_LOG_MAX_SIZE_MB`	1	Max audit log file size (MB)

Custom Users

docker run \
  -e MALACHI_ADMIN_PASS="your_admin_password" \
  -e MALACHI_DEFAULT_USERS="user1:pass1:produce,consume;user2:pass2:admin" \
  hectorcardoso/malachi:latest

Format: username:password:permission1,permission2;...

Permissions: admin, produce, consume

🔒 TLS/SSL Encryption

⚠️ IMPORTANT: For production deployments, always enable TLS to encrypt credentials and messages.

Quick Start with TLS

1. Generate Development Certificates

./scripts/generate-dev-certs.sh

2. Run with TLS Enabled

docker run \
  -p 4040:4040 \
  -v $(pwd)/priv/cert:/certs \
  -e MALACHI_ADMIN_PASS="your_secure_password" \
  -e MALACHI_ENABLE_TLS=true \
  -e MALACHI_TLS_CERTFILE=/certs/server.crt \
  -e MALACHI_TLS_KEYFILE=/certs/server.key \
  hectorcardoso/malachi:latest

3. Connect with TLS Client (Node.js)

const tls = require('tls');

const client = tls.connect({
  host: 'localhost',
  port: 4040,
  rejectUnauthorized: false  // For self-signed certs (dev only)
}, () => {
  console.log('TLS connected');
  client.write(JSON.stringify({
    action: 'auth',
    username: 'producer',
    password: 'producer123'
  }) + '\n');
});

Production TLS Setup

For production, use certificates from:

Let's Encrypt (free, automated)
DigiCert, GlobalSign (commercial CAs)
Internal PKI (corporate environments)

TLS Features

✅ TLS 1.2 and 1.3 support
✅ Strong cipher suites (ECDHE, AES-GCM)
✅ Perfect Forward Secrecy
✅ Mutual TLS (mTLS) support
✅ Backward compatible (TLS is optional)

Inter-node TLS (Erlang distribution)

The sections above secure the client connection (port 4040). In a multi-node cluster the nodes also talk to each other over Erlang distribution (the ra control plane and segment replication), by default that traffic is plaintext, guarded only by the distribution cookie. Set MALACHI_DIST_TLS=true to run distribution over mutual TLS instead: each node presents a CA-signed certificate and verifies its peers, so the inter-node traffic is encrypted and authenticated.

# generate a dev CA + node cert + a ready ssl_dist options file
bash scripts/generate-dist-certs.sh

# run a release with inter-node TLS (the script prints this line with real paths)
MALACHI_DIST_TLS=true \
MALACHI_DIST_TLS_OPTFILE=$PWD/priv/dist_cert/dist_tls.conf \
  bin/malachi start

MALACHI_DIST_TLS_OPTFILE points at an ssl_dist options file (server + client cert/key/CA, verify_peer); the release's rel/env.sh.eex translates the flag into -proto_dist inet_tls. A node without TLS cannot join a TLS cluster: the handshake rejects it. The Kubernetes example wires this up (the malachi-dist-tls Secret + the two env vars).

🔐 Dashboard Security

The web dashboard (port 4041) requires authentication in production, so an unauthenticated client cannot reach it. Set MALACHI_DASHBOARD_AUTH_ENABLED=false only for local development.

Required Configuration

You MUST configure dashboard credentials when deploying to production:

# Option 1: Use existing admin user credentials
docker run \
  -e MALACHI_DEFAULT_USERS="admin:your_strong_password:admin" \
  hectorcardoso/malachi:latest

# Option 2: Separate dashboard credentials (recommended)
docker run \
  -e MALACHI_DASHBOARD_USER="dashboard_admin" \
  -e MALACHI_DASHBOARD_PASS="dashboard_secure_pass_123" \
  hectorcardoso/malachi:latest

Accessing the Dashboard

Browser Access

Navigate to http://localhost:4041/login
Enter your credentials
Token is stored in browser localStorage
Auto-redirect on token expiry

API Access with Bearer Token

# Get token via login endpoint
TOKEN=$(curl -X POST http://localhost:4041/login \
  -H "Content-Type: application/json" \
  -d '{"username":"admin","password":"your_password"}' \
  | jq -r '.token')

# Access dashboard with token
curl -H "Authorization: Bearer $TOKEN" http://localhost:4041/metrics

# SSE stream with token
curl -H "Authorization: Bearer $TOKEN" http://localhost:4041/stream

Using Existing Session Tokens

Malachi session tokens (from TCP authentication) can be used for dashboard access if the user has :admin permission:

# Authenticate via TCP to get token
TOKEN="your_tcp_session_token"

# Use token for dashboard
curl -H "Authorization: Bearer $TOKEN" http://localhost:4041/

Configuration Options

Environment Variable	Default	Description
`MALACHI_DASHBOARD_AUTH_ENABLED`	`true` (prod)	Enable/disable dashboard auth
`MALACHI_DASHBOARD_REQUIRE_ADMIN`	`true`	Require `:admin` permission for HTML/SSE
`MALACHI_DASHBOARD_AUTH_RATE_LIMIT`	`10`	Max auth attempts per window
`MALACHI_DASHBOARD_AUTH_RATE_WINDOW_MS`	`60000`	Rate limit window (1 minute)
`MALACHI_DASHBOARD_CORS_ENABLED`	`false`	Enable CORS for `/metrics` and `/stream`
`MALACHI_DASHBOARD_CORS_ORIGINS`	`*`	Allowed CORS origins (comma-separated)
`MALACHI_DASHBOARD_CSP`	(default)	Custom Content-Security-Policy
`MALACHI_HSTS_ENABLED`	`true`	Enable HTTP Strict Transport Security
`MALACHI_HSTS_MAX_AGE`	`31536000`	HSTS max-age (1 year)

Disabling Authentication (NOT RECOMMENDED)

For development environments only:

docker run \
  -e MALACHI_DASHBOARD_AUTH_ENABLED=false \
  hectorcardoso/malachi:latest

⚠️ WARNING: Never disable authentication in production or internet-facing deployments.

Permission Model

/ (Dashboard HTML) and /stream (SSE): Require :admin permission (configurable)
/metrics and /rate_limits: Allow any authenticated user
/login: Public endpoint (no authentication required)

Security Headers

All dashboard responses include comprehensive security headers:

Content-Security-Policy (CSP): Prevents XSS attacks
X-Frame-Options: Prevents clickjacking
X-Content-Type-Options: Prevents MIME-sniffing
X-XSS-Protection: Legacy XSS protection
Referrer-Policy: Controls referrer information
Strict-Transport-Security (HSTS): Enforces HTTPS (when TLS enabled)

CORS Configuration

For web applications accessing metrics:

docker run \
  -e MALACHI_DASHBOARD_CORS_ENABLED=true \
  -e MALACHI_DASHBOARD_CORS_ORIGINS="https://app.example.com,https://admin.example.com" \
  hectorcardoso/malachi:latest

With an explicit list, the request's own Origin is echoed back when it is on the list, and nothing is sent when it is not: Access-Control-Allow-Origin carries a single origin, never the whole list. The default * answers every origin. The OPTIONS preflight applies the same rules, so it never advertises access the real request would be denied.

Only /metrics and /stream are cross-origin endpoints, and a preflight for any other path is refused. Note what that does and does not buy: CORS decides whether a browser lets a page read a response, not what reaches the server. Refusing the preflight blocks the cross-origin requests that need one (a custom header, a JSON content type), but a CORS-simple request still arrives and is processed, with its response unreadable to the caller. What keeps such a request unprivileged is the session cookie being SameSite=Strict, so it is not sent cross-origin at all.

Credentials are never part of a cross-origin exchange here: no Access-Control-Allow-Credentials is sent, so a cross-origin caller authenticates with a Bearer token. That also makes /stream same-origin only, since an EventSource cannot set headers.

🔍 Audit Logging

Malachi includes comprehensive audit logging for security-relevant events.

Configuration

Environment Variable	Default	Description
`MALACHI_AUDIT_LOG_OUTPUT`	`both`	Output mode: `file`, `stdout`, `both`, `ets_only`
`MALACHI_AUDIT_LOG_FILE`	`/var/log/malachi/audit.log`	Audit log file path
`MALACHI_AUDIT_LOG_MAX_SIZE_MB`	`1`	Max file size in MB (auto-rotation)

Output Modes

# File only (traditional deployments)
-e MALACHI_AUDIT_LOG_OUTPUT=file \
-e MALACHI_AUDIT_LOG_FILE=/var/log/malachi/audit.log

# Stdout only (container/cloud environments)
-e MALACHI_AUDIT_LOG_OUTPUT=stdout

# Both file and stdout
-e MALACHI_AUDIT_LOG_OUTPUT=both

# ETS only (no file/stdout, in-memory only)
-e MALACHI_AUDIT_LOG_OUTPUT=ets_only

Logged Events

All events are logged in JSON format with full context:

Authentication: auth_success, auth_failure, auth_lockout
Sessions: session_created, session_revoked, session_expired, session_hijack_attempt
Dashboard: dashboard_access, dashboard_login_success, dashboard_auth_failure
Administrative: account_unlocked, config_validation_failed

Example Audit Log Entry

{
  "timestamp": "2026-02-09T15:30:45.123Z",
  "event_id": "a1b2c3d4e5f6",
  "event_type": "dashboard_access",
  "actor": {
    "username": "admin",
    "ip": "192.168.1.100"
  },
  "action": "http_GET_/metrics",
  "result": "success",
  "metadata": {
    "path": "/metrics",
    "method": "GET"
  },
  "hostname": "malachi-prod-01",
  "node": "malachi@localhost"
}

File Rotation

Audit logs automatically rotate when exceeding AUDIT_LOG_MAX_SIZE_MB:

Only the most recent events are kept
Rotation maintains valid JSON lines
No external tools required (logrotate not needed)

Querying Audit Logs

Via Elixir API:

# Get recent events
Malachi.AuditLog.get_events(100)

# Get events by type
Malachi.AuditLog.get_events_by_type(:dashboard_access, 50)

# Get events by user
Malachi.AuditLog.get_events_by_user("admin", 50)

# Get statistics
Malachi.AuditLog.get_stats()

🛡️ Security Hardening

Production Checklist

Content Security Policy (CSP)

The default CSP allows 'unsafe-inline' for compatibility. For maximum security, use a stricter policy:

docker run \
  -e MALACHI_DASHBOARD_CSP="default-src 'self'; script-src 'self'; style-src 'self'; img-src 'self' data:" \
  hectorcardoso/malachi:latest

Note: Removing 'unsafe-inline' requires refactoring dashboard HTML to use external script/style files or nonces. This is planned for a future release.

Rate Limiting

Dashboard authentication is rate-limited to prevent brute-force attacks:

Default: 10 attempts per 60 seconds per IP
Failed attempts trigger account lockout (configurable)
Rate limits apply to both /login endpoint and Bearer token validation

Security Metrics

Monitor security metrics via /metrics endpoint:

curl -H "Authorization: Bearer $TOKEN" http://localhost:4041/metrics | jq '.system.security'

Returns:

{
  "failed_auth_attempts": 5,
  "account_lockouts": 1,
  "active_sessions": 12,
  "dashboard": {
    "auth_success": 150,
    "auth_failed": 5,
    "auth_blocked": 2
  }
}

📡 Client protocol

External clients connect to port 4040 and speak a compact binary protocol (Malachi.Wire). Every message is a length-prefixed frame:

Frame:     <<len::32, body>>
Request:   <<api_key::16, correlation_id::32, payload>>
Response:  <<correlation_id::32, error_code::16, payload>>   # error_code 0 = ok, 1 = error (reason string)

correlation_id lets a client pipeline (match each response to its request). api_key selects the operation:

api_key	operation	notes
0	`auth`	required first frame; `username`/`password` → session token
1	`create_topic`	topic name + keyspace bits
2	`produce`	topic + records (routed by key); returns the produced count
3	`fetch`	topic + opaque cursor / consumer group / group member → records + cursor
4	`commit`	durably commit a consumer group's position (from a cursor)
5	`subscribe`	open a server-push stream for a group (or a group member), bounded by a credit window
6	`stream_ack`	ack N streamed records: commit the position and return credit (a member ack also heartbeats)
7	`leave_group`	remove a member from its group (fast rebalance on clean shutdown)

Records on the wire carry no offset: position travels only in the opaque cursor, and permissions (:produce/:consume) are enforced per operation against the authenticated session.

A fetch with a consumer-group member id is server-scoped: the coordinator assigns each member of a group a share of the topic's ranges, so members consume in parallel and disjointly. The client still only sees records + an opaque cursor: ranges never cross the wire - and the member stays alive by fetching (or explicitly leave_groups on shutdown).

Streaming (subscribe/stream_ack) is the NorthGuard-style sessionized push: after subscribing, the server pushes records up to the credit window; the client acks to durably advance the group's position (at-least-once) and return credit, so a slow consumer applies backpressure instead of overflowing. A subscribe with a member id scopes the push stream to that member's ranges (parallel, disjoint, still opaque); the member ack doubles as a coordinator heartbeat, so an idle member sends a periodic empty ack to stay alive (and leave_groups on shutdown for a fast rebalance). A member's coordination is owned by one node (the leader of the topic's vnode); during a leadership failover a member request may briefly get not_owner, which is transient: the reference client backs off and retries (the server re-resolves the new leader).

Reference client (Node.js)

scripts/ ships a dependency-free Node.js reference client that speaks the protocol above:

scripts/lib/wire.js: the binary codec, a direct port of Malachi.Wire (framing, envelope, records).
scripts/lib/client.js: a connection that multiplexes requests by correlation_id and routes push frames to a subscription callback.
scripts/producer.js / consumer.js / subscriber.js, CLIs for append, pull, and server-push.

# append 100 records to a topic (creating it first)
node scripts/producer.js orders 100 --create

# pull with a resumable consumer group, long-polling for new records
node scripts/consumer.js orders --group workers --follow

# parallel consumption: several members of one group each get a share of the ranges (opaque, disjoint)
node scripts/consumer.js orders --group workers --member c1 &
node scripts/consumer.js orders --group workers --member c2 &

# server-push streaming (subscribe + credit-windowed acks)
node scripts/subscriber.js orders --group live

# parallel server-push: several members of one group, each streamed a disjoint share (opaque)
node scripts/subscriber.js orders --group live --member s1 &
node scripts/subscriber.js orders --group live --member s2 &

# end-to-end demo (append, then stream while producing)
bash scripts/streaming-demo.sh

Default credentials: producer/producer123 (produce + create-topic), consumer/consumer123 (consume), app/app123 (both). Override with MALACHI_USER/MALACHI_PASS; point at another server with MALACHI_HOST/MALACHI_PORT. The same flow is exercised in-VM by Malachi.Test.TCPHelper (test/support/tcp_helper.ex).

Load test

scripts/loadtest.js is a load generator built on the same client, in two modes. Closed-loop (default) runs N connections in a tight op → await loop to find the ceiling and the latency at saturation. Open-loop (--rate <rps>) fires requests at a fixed arrival rate and measures latency from each request's scheduled time: correcting coordinated omission, so a stall shows up as latency on the requests that queued behind it. Both report throughput (ops/s, records/s, MB/s) and latency percentiles (p50/p90/p95/p99).

# closed-loop: max produce throughput, 20 connections for 10s
node scripts/loadtest.js --scenario produce --connections 20 --duration 10

# open-loop: hold 1500 req/s and see the coordinated-omission-corrected latency
node scripts/loadtest.js --scenario produce --rate 1500 --duration 10

# fetch a 50k-record backlog, 200 records/pull
node scripts/loadtest.js --scenario fetch --prepopulate 50000 --max 200

# server-push streaming throughput
node scripts/loadtest.js --scenario stream --connections 4 --window 500

# mixed produce+fetch under contention, 512-byte records
node scripts/loadtest.js --scenario mixed --connections 20 --record-size 512 --json

Latency is stored in a bounded reservoir (percentiles stay representative on long runs while min/max remain exact). --help lists every flag.

🛠️ Development

Prerequisites

Elixir 1.19+
Erlang/OTP 28+

Note: mix.exs requires ~> 1.19, so earlier Elixir versions do not compile. OTP 28 is what CI and the Docker image build against; older OTP releases are not tested or supported.

Initial Setup

After cloning the repository, run the setup script to install git hooks:

./scripts/setup-dev.sh

This will:

Install Lefthook (git hooks manager)
Configure a pre-commit hook that runs mix format
Ensure all developers have consistent git hooks

The pre-commit hook runs mix format and re-stages any .ex/.exs files it reformats. To skip: git commit --no-verify

Run Locally

mix deps.get
mix run --no-halt

Run Tests

mix test

Build Docker Image Locally

make docker-build
make docker-run

Available Make Commands

make build          # Install deps and compile
make run            # Run locally
make test           # Run tests
make release        # Build production release
make docker-build   # Build Docker image
make docker-run     # Run Docker container
make docker-stop    # Stop Docker container
make docker-push    # Push to Docker Hub
make compose-up     # Start with docker-compose
make compose-down   # Stop docker-compose
make clean          # Clean build artifacts

Code Quality Checks

# Format code
mix format

# Check formatting
mix format --check-formatted

# Run static analysis
mix credo --strict

# Check for security issues
mix deps.audit

# Check for unused dependencies
mix deps.unlock --check-unused

CI/CD

The project uses GitHub Actions for continuous integration:

✅ Automated Tests - Run on every commit
✅ Multiple Elixir/OTP Versions - Tested on 3 versions
✅ Code Quality - Credo, formatting, security checks
✅ Docker Build - Verified on every PR
✅ Automatic Releases - On merge to main
✅ Security Scanning - Gitleaks, Trivy, Sobelow on every PR
✅ Performance Benchmarks - Automated regression detection on PRs
✅ Daily Security Scans - Scheduled vulnerability scanning (2 AM UTC)

See the CI workflow for details.

🌍 Internationalization (i18n)

Malachi supports Brazilian Portuguese (pt_BR) and American English (en_US).

Configuration

config :malachi, locale: "pt_BR"

Runtime Change

Malachi.I18n.set_locale("en_US")
Malachi.I18n.locale()

📊 User Management (Elixir)

Malachi.Auth.list_users()
Malachi.Auth.add_user("myuser", "mypass", [:produce, :consume])
Malachi.Auth.remove_user("myuser")
Malachi.Auth.change_password("myuser", "newpass")

🏗️ Architecture

Malachi ports LinkedIn's NorthGuard log-storage design to Elixir/OTP:

Control plane: topic/range/segment metadata as a deterministic state machine, replicated per vnode by Raft (ra) and sharded across vnodes by topic.
Data plane: a Log of segments per range, replicated by quorum across nodes; placement is HRW/rendezvous and rack-aware.
Membership: SWIM (gossip with suspicion) for failure detection; self-healing re-replicates segments and promotes primaries on node loss.
Client: a compact binary protocol over TCP; topics, keys, and opaque cursors (never partitions or offsets).

See docs/ARCHITECTURE.md for the full design.

📄 License

MIT License

🤝 Contributing

We welcome contributions! Please follow these guidelines:

Before You Start

Check existing issues and PRs
Discuss major changes in an issue first
Read the CI workflow

Development Process

Fork the repository
Create a feature branch (git checkout -b feat/amazing-feature)
Make your changes with tests
Run quality checks:
```
mix format
mix test
mix credo --strict
```

Commit using Conventional Commits:

git commit -m "feat: add amazing feature"

Push to your fork (git push origin feat/amazing-feature)
Open a Pull Request

PR Requirements

✅ Tests - All new features must include tests
✅ Documentation - Update relevant docs
✅ CI Passing - All checks must pass
✅ Conventional Commits - Follow commit format
✅ Code Review - Address review feedback

Commit Message Format

<type>: <description>

Examples:
- feat: add TLS support
- fix: resolve authentication bug
- docs: update README
- test: add unit tests for Auth module
- chore: update dependencies

Types:

feat: - New feature (→ minor version)
fix: - Bug fix (→ patch version)
docs: - Documentation
test: - Tests
refactor: - Code refactoring
chore: - Maintenance

Breaking Changes:

Add [major] to title or BREAKING CHANGE: in body

📋 Input validation

Malachi validates untrusted input at the connection boundary: a malformed frame is answered with an error, never a crash.

Topic names: an allowlist that is path-traversal safe (a topic name becomes an on-disk directory name): allowed characters A-Z a-z 0-9 . _ -, non-empty, and never . or ... Enforced deterministically in the control plane (Malachi.Metadata), so it holds identically on every replica.

valid:    orders   user.events   app-logs_v2   api.v1.payments
invalid:  "my topic" (space)   api/v1/events (slash)   user:session (colon)   ""   .   ..

Frame size. The binary protocol rejects a frame whose declared length exceeds :max_frame_size (application config, default 16 MiB) at the 4-byte length prefix, before the body is buffered, so a hostile length prefix cannot exhaust memory.

Records: a record's value is arbitrary bytes (non-UTF-8 survives the round trip); headers are key/value byte-string pairs. Both are bounded by the frame cap, and records carry no client-visible offset.

The underlying security infra: authentication (Argon2), rate limiting, connection limits, account lockout, audit logging, is covered above and in SECURITY.md.

🔖 Versioning

This project uses SEMVER with automated releases.

Patch: Bug fixes → Add patch label or default
Minor: New features → Add minor label or use feat: prefix
Major: Breaking changes → Add major label or use [major] in title

See the GitHub Releases for the per-version change history.

Name		Name	Last commit message	Last commit date
Latest commit History 378 Commits
.github		.github
.vex		.vex
benchmark		benchmark
config		config
deploy/kubernetes		deploy/kubernetes
docs		docs
lib		lib
priv/static		priv/static
rel		rel
scripts		scripts
test		test
.credo.exs		.credo.exs
.formatter.exs		.formatter.exs
.gitattributes		.gitattributes
.gitignore		.gitignore
.pre-commit-config.yaml		.pre-commit-config.yaml
.sobelow-conf		.sobelow-conf
Claude.md		Claude.md
Dockerfile		Dockerfile
Git Provider.ini		Git Provider.ini
LICENSE		LICENSE
Makefile		Makefile
README.md		README.md
SECURITY.md		SECURITY.md
coveralls.json		coveralls.json
docker-compose.yml		docker-compose.yml
lefthook.yml		lefthook.yml
mix.exs		mix.exs
mix.lock		mix.lock
pre-commit.sh		pre-commit.sh

Uh oh!

Folders and files

Latest commit

History

Repository files navigation

Malachi

💖 Sponsors

Backers

Introduction

🧭 The model (a log, not a queue)

⚡ Getting started (local)

Node discovery (libcluster)

🚀 Quick Start with Docker

Pull and Run

Using Docker Compose

Build Locally (All Platforms)

🛡️ Security Features

📦 Ports

📈 Observability

Prometheus metrics

Telemetry events

Tracing (OpenTelemetry)

🔐 Authentication

Default Users (development)

First boot in production

Environment Variables

Custom Users

🔒 TLS/SSL Encryption

Quick Start with TLS

1. Generate Development Certificates

2. Run with TLS Enabled

3. Connect with TLS Client (Node.js)

Production TLS Setup

TLS Features

Inter-node TLS (Erlang distribution)

🔐 Dashboard Security

Required Configuration

Accessing the Dashboard

Browser Access

API Access with Bearer Token

Using Existing Session Tokens

Configuration Options

Disabling Authentication (NOT RECOMMENDED)

Permission Model

Security Headers

CORS Configuration

🔍 Audit Logging

Configuration

Output Modes

Logged Events

Example Audit Log Entry

File Rotation

Querying Audit Logs

🛡️ Security Hardening

Production Checklist

Content Security Policy (CSP)

Rate Limiting

Security Metrics

📡 Client protocol

Reference client (Node.js)

Load test

🛠️ Development

Prerequisites

Initial Setup

Run Locally

Run Tests

Build Docker Image Locally

Available Make Commands

Code Quality Checks

CI/CD

🌍 Internationalization (i18n)

Configuration

Runtime Change

📊 User Management (Elixir)

🏗️ Architecture

📄 License

🤝 Contributing

Before You Start

Development Process

PR Requirements
