Water Tracing Dashboard

Introduction

Basic running instructions

The following list defines the basic steps required to set up and run the digital twin.

Requirements

• Docker

Officially Supported Operating Systems

• Windows 10/11
• Ubuntu 22.04

Note: Other Linux-based operating systems are likely to work but have not been as thoroughly tested.

Unsupported Operating Systems

We unfortunately do not support MacOS. Please see #358 for updates or to contribute.

Required Credentials:

Create API keys for each of these services. You may need to create an account and log in

• Stats NZ API Key
• LINZ API Key
• MFE API Key
• NIWA Application API Key - Create an app that has the Tide API enabled.
• Cesium Ion Access Token

Starting the Digital Twin application (localhost)

1. Clone this repository to your local machine.

2. Create a file called api_keys.env, copy the contents of api_keys.env.template and fill in the blank values with API credentials from the above links.

3. Create a file called .env in the project root, copy the contents of .env.template and fill in all blank fields unless a comment says you can leave it blank. Blank fields to fill in include fields such as CESIUM_ACCESS_TOKEN and POSTGRES_PASSWORD. POSTGRES_PASSWORD can be a password of your choosing. You may modify other configuration variables if needed to suit particular deployment environemnts.

4. From project root, run the command docker compose up -d to run the database, backend web servers, and helper services.

5. You may inspect the logs of the backend using docker compose logs -f backend celery_worker

Using the Digital Twin application

1. With the docker compose application running, the default web address is http://localhost:3001 to view the web application.
   • To perform custom modelling, "Explore map data" has configurable models.
2. The API is available by default on http://localhost:5000. Visit https://geospatialresearch.github.io/Digital-Twins/swagger for API documentation.

Contributing

If you are interested in contributing to this project, please see our contributing page here.

Support

If you run into an issue, bug, or need help with the software, please consider opening an issue or discussion, this will be the best way to reach us.

Setup for FReDT project software developers

Visit our wiki for some instructions on how to set up your development machine to work with on the FReDT project.
